Motorcycle
VR-220HX (DB01A)
- Features
- New High-Performance 6-Speed International Gearbox Engine
- Max Power: 13.8 kW / 8250 rpm
- Suspension System
- Front: 43mm Inverted Front Fork with Adjustable Damping
- Rear: Central Mono Shock with Multi-Link Suspension
- Braking System
- Caliper: Single-direction Dual-Piston Caliper
- Brake Discs: Front 240mm / Rear 220mm
- Additional Features
- Dual Throttle Cables
- Design Highlights
- Factory-Fitted H4 Round Headlamp
- Multifunction Full-Color LCD Instrument Panel
- High-Rigidity Cradle Frame
- Integrated Off-Road Style Safety Seat
- Spoke Rims with 21” Front / 18” Rear Off-Road Tires
| Engine Type / Cooling System | 4-Stroke, 4-Valve, SOHC, Air Cooled |
|---|---|
| Total Exhaust Volume (C.C.) | 223 c.c |
| Compression ratio | 9.2:1 |
| Dimension | 2082 x 823 x 1240 mm |
| Wheel Base | 1370 mm |
| Dry Weight | 137 kg |
| Start Up | Electric |
| Fuel Supply | CDI |
| Transmission System | Wet Multi-plate |
| Front Suspension System | Inverted |
| Rear Suspension System | Mono shock |
| Front Brake | DISC |
| Rear Brake | DISC |
| Front Tire Size and Layer | 3.0-21 51P |
| Rear Tire Size and Layer | 110/80-18 58P |
| Fuel Tank Capacity | 12 L |
| Fuel Consumption rate | 30.59 km/L |
⚠️Please note that the motorcycle models and specifications listed are for sale in the Taiwan market only. Specifications may vary in other countries (such as Nepal, Sri Lanka, the UAE, etc.) Please consult your local distributor for detailed local specifications.
